Product Overview
The FQ-U316H USB 3.1 Gen2 Fiber Optic Extender is a high-speed USB extension solution designed to transmit USB 3.1 Gen2 and USB 3.0 SuperSpeed signals over long distances using multimode optical fiber.
Supporting data rates up to 10Gbps, the extender can transmit USB signals up to 100 meters over 2-core OM3/OM4 multimode LC fiber. Optical transmission provides excellent resistance to electromagnetic interference and enables stable, low-loss signal transmission in demanding environments.
The system features a USB Type-C male to USB Type-A male connection and consists of a host-side receiver and device-side transmitter. The host side can be powered through a standard USB Type-A port or auxiliary Micro USB power when additional power is required. The device side uses external power and provides power to the connected USB device through the USB Type-C interface.
The FQ-U316H is plug and play and does not require additional driver software, making it suitable for machine vision, industrial video transmission, high-speed data acquisition, remote storage, and professional USB applications.
Key Features
- USB 3.1 Gen2 and USB 3.0 SuperSpeed transmission
- Supports data rates up to 10Gbps
- Extends USB signals up to 100m
- Uses 2-core OM3/OM4 multimode optical fiber
- LC optical interface
- USB Type-C Male to Type-A Male
- 850nm VCSEL array technology
- Built-in micro diffractive optical system
- Uncompressed, low-loss optical transmission
- Excellent resistance to electromagnetic interference
- Provides power to connected USB 3.1 Gen2 / USB 3.0 devices
- Standard USB Type-A 5V/900mA power supply
- Micro USB auxiliary power supported when additional power is required
- Plug and play with no driver software required
- Not compatible with USB 2.0 or USB 1.1
Applications
- Kinect and motion-sensing peripherals
- Industrial video transmission
- Machine vision systems
- High-definition surveillance systems
- High-speed data acquisition
- Remote storage systems
- Digital signage and video walls
- Industrial printer systems
- Professional USB 3.0 applications
