Product Overview
The FQ-2S-KN4A-T/R 2-Channel 3G-SDI Fiber Optic Extender is a professional rackmount transmission system designed to transmit 2 channels of SD-SDI, HD-SDI, and 3G-SDI video together with 4 channels of unidirectional balanced XLR audio over a single optical fiber.
The system supports video resolutions up to 1920×1080@60Hz and SDI transmission rates from 270Mbps to 3Gbps. Four channels of balanced XLR audio are digitally sampled at 24-bit/192kHz, providing high-quality audio transmission with low noise and interference.
Using single-mode single-fiber LC transmission, the system supports transmission distances of up to 20km. The 19-inch 1U rackmount design and built-in AC 220V power supply make it suitable for broadcast studios, control rooms, live events, and professional AV installations.
Key Features
- Supports 2-channel SD-SDI, HD-SDI, and 3G-SDI video
- Supports resolutions up to 1920×1080@60Hz
- 4-channel unidirectional balanced XLR audio transmission
- 24-bit/192kHz digital audio sampling
- Low-noise, interference-resistant digital audio transmission
- 20km transmission over single-mode single-fiber LC
- Supports 270Mbps, 1.48Gbps, and 3Gbps SDI rates
- Supports SMPTE-424M, SMPTE-292M, SMPTE-259M, and DVB-ASI
- Professional 19-inch 1U rackmount design
- Built-in AC 220V power supply
Applications
- Broadcast studios and TV stations
- Professional audio and video transmission
- Live events and concert production
- OB and mobile broadcast systems
- Studio-to-control-room transmission
- Long-distance SDI video and audio distribution
- Professional AV and stage systems
