Product Overview
The FQ-THL610HKM-T/R HDMI KVM Fiber Optic Extender transmits high-definition HDMI video and audio over a single fiber optic cable while providing remote keyboard and mouse control, bi-directional RS232 data, and bi-directional analog audio transmission.
Supporting resolutions up to 1920×1200@60Hz / 1920×1080@60Hz, the extender provides stable and uncompressed digital video transmission over long distances. Both the transmitter and receiver feature one HDMI loop-through output, allowing the local and remote video signals to be monitored or connected to additional displays.
The system supports single-mode fiber transmission up to 10km and OM3 multimode fiber up to 300m. Its plug-and-play design, EDID learning, automatic equalization, and ESD protection make it suitable for professional AV and industrial applications.
Key Features
- HDMI video transmission over a single fiber optic cable
- Supports up to 1920×1200@60Hz / 1920×1080@60Hz
- KVM functionfor remote keyboard and mouse control
- Bi-directional RS232 transmission up to 115200bps
- One-channel bi-directional analog stereo audio
- HDMI loop-through on both transmitter and receiver
- Single-mode fiber transmission up to 10km
- OM3 multimode fiber transmission up to 300m
- HDMI 1.3 and HDCP 1.2 compliant
- Supports EDID learning and automatic display mode configuration
- Automatic equalization for stable video transmission
- Plug and play with no software configuration required
- ESD protection for improved system reliability
Applications
- Exhibition and display systems
- Video conferencing
- Broadcast and television
- Railway and transportation systems
- Medical training and teaching
- Education and lecture recording
- Projection and video wall systems
- Control rooms and monitoring centers
- Industrial AV systems
- Long-distance KVM extension
