Product Overview
The FQ-MOD168 RS485/RS422/RS232 Fiber Optic Converter is a professional serial data fiber transmission solution designed for long-distance transmission of RS485, RS422, and RS232 data over optical fiber.
The converter supports 2 channels of RS485 or 1 channel of RS422, with both full-duplex and half-duplex operation, asynchronous point-to-point transmission, and data rates up to 250Kbps. It also provides 1 full-duplex RS232 interface with asynchronous point-to-point transmission at data rates up to 115.2Kbps.
The FQ-MOD168 supports single-mode or multimode fiber, as well as single-fiber or dual-fiber transmission, with SC, FC, or ST optical interfaces. Depending on the selected optical configuration, transmission distances are available from 2km to 20km.
With a compact 95 × 70 × 25mm design, the converter can be powered locally using an external DC 5V/1A power supply or installed in a compatible 14-slot dual-power rack for centralized power distribution.
Key Features
- Supports RS485 / RS422 / RS232serial data transmission
- Supports 2-channel RS485 or 1-channel RS422
- Supports full-duplex and half-duplex RS485/RS422 operation
- Supports 1-channel full-duplex RS232
- Asynchronous point-to-point data transmission
- RS485/RS422 data rate up to 250Kbps
- RS232 data rate up to 2Kbps
- 155Mbps optical transmission rate
- Supports single-mode and multimode fiber
- Supports single-fiber and dual-fiber configurations
- Available with SC, FC, or ST optical interfaces
- Transmission distance up to 20km
- Phoenix terminal serial interface
- Supports 14-slot dual-power rack centralized power
- Compact 95 × 70 × 25mm enclosure
- Suitable for industrial control and serial communication applications
Applications
- Industrial automation and control systems
- RS485/RS422/RS232 long-distance communication
- PLC and industrial controller communication
- Serial device networking
- Building automation systems
- Security and access control systems
- Traffic control and monitoring systems
- Remote instrumentation and data acquisition
- Factory and process control
- Long-distance serial data transmission
